Display : 5″ Touch Screen
Face Capacity : 6,000 (Optional:10,000)
Palm Capacity : 3,000 (Customized)
Card Capacity : 10,000
Transaction Capacity : 200,000（Optional: 500k）
Operation System : Linux
:Functions
ID Card, ADMS, DNS, T9 Input, DST, Camera, 9-digit User ID, Advance Access Control , Groups, Holidays, Anti-passback, Record Query, Tamper Switch Alarm , Bell Scheduling , POE (Optional, IEEE 802.3at-2009)
:Hardware
1GHz Dual Core CPU / 1G RAM / 8G Flash / 2MP WDR Low Light Camera / Adjustable LED Supplement Lighting / Rain Cover (Optional)
Communication :TCP / IP, Wi-Fi (Optional), Wiegand Input / Output, RS485*
Access Control Interface:3rd-party Electric Lock, Door Sensor, Exit Button, Alarm Output, Aux. Input
Optional Card Module:IC / HID / iClass / Felica / Desfire EV1 / EV2 / Legic
Facial Recognition Speed:≤ 0.5s per face
Biometrics Algorithm:ZKFace V5.8 & ZKPalm V12.0 (Customized)
Ingress Protection Rating:IP66
: Power Supply
Voltage: DC 12V
Current: Max. 3A
Operating Humidity:10% to 90%
Operating Temperature:-30°C to 60°C
Dimension 103.83 * 212.41 * 50.60 (mm) (W*H*D)
Supported Software :ZKBio CVAccess
